VITEC MGW Ace Encoder Compact HEVC (H.265)

VITEC MGW Ace Encoder Compact HEVC (H.265)

1080p60 4:2:2 10-bit HEVC encoding from SDI, HDMI and Composite
Ultra Low Latency mode
HDR support, Closed captions, AES encryption and x16 audio encoding channels
2x 1Gb/s network for streaming and management
KLV/STANAG metadata processing
Portable, low-power hardware design

MGW Ace Encoder is an HEVC / H.265 hardware encoder packaged in a professional grade portable streaming appliance.

It delivers the industry’s best video quality, enabling users to stream broadcast quality HD/SD video with up to 50% bandwidth savings compared to H.264.

Additionally, the codec supports Ultra Low Latency streaming in HEVC for a glass-to-glass latency down to 16ms.

From live news broadcasting in the field, point-to-point contribution of HD video, live streaming from or within sports venues to distribution of mission-critical military imagery, the MGW Ace makes it more efficient than ever to deliver the highest quality IPTV streams over satellite links, private networks and over the internet.

ALSO AVAILABLE : VITEC MGW Diamond-H 4k Video Encoder, one Channel, SRT and ULL licences

VITEC MGW ACE one Channel 2k , SRT and ULL LicenseZ, HDMI and SDI in

VITEC E3830 HD, h264 full HD. SRT License, HDMI in

The VITEC MGW Ace Encoder Compact HEVC (H.265) is a portable, professional-grade video encoder designed for high-efficiency video encoding and streaming. It is commonly used in broadcast and live video streaming applications.

Key Features:

• Video Encoding Format:

  • HEVC (H.265)
  • H.264 (AVC) supported in some configurations

• Resolution Support:

  • Up to 4K UHD (3840×2160) at 60 fps
  • Supports 1080p and 720p resolutions as well

• Encoding Bitrate:

  • Variable bitrate support up to 30 Mbps for high-quality live video transmission
  • The bitrate can be adjusted for network conditions and content type

• Latency:

  • Low latency encoding, ideal for live video streaming applications
  • End-to-end latency as low as 100ms (depending on configuration)

• Audio Support:

  • AAC-LC audio encoding
  • Supports embedded audio (via HDMI or SDI) or external line-level audio input

• Connectivity:

  • 1 x Gigabit Ethernet (for streaming via RTMP, HLS, SRT, UDP, RTP, and RTSP)
  • Optional 3G-SDI input/output
  • HDMI input (for both video and audio)
  • Audio input (XLR or line-level)

• Supported Streaming Protocols:

  • RTMP (Real-Time Messaging Protocol)
  • RTSP (Real-Time Streaming Protocol)
  • HLS (HTTP Live Streaming)
  • SRT (Secure Reliable Transport) for low-latency streaming over unreliable networks
  • UDP/RTP for traditional broadcast use
  • MPEG-TS (Transport Stream) over UDP for contribution or broadcast systems

• Control Interface:

  • Web-based GUI (Graphical User Interface) for easy configuration and management
  • Support for SNMP (Simple Network Management Protocol) for remote monitoring
  • RESTful API for integration with other systems and automation

• Power:

  • 12V DC input, with a power consumption of approximately 15-20W (depending on the configuration)
  • Optional battery-operated solutions for mobile deployments

• Form Factor:

  • Compact, rack-mountable design (1U or tabletop configuration options)
  • Weight: Approximately 1.5-2 kg (varies based on specific configuration)
  • Dimensions (L x W x H): Approximately 19 x 14 x 4 cm for the compact unit

• Advanced Features:

  • Hardware-based encoding: Ensures optimized performance with low latency and high-quality output
  • Multi-channel audio support: Transmit multiple channels of audio with video feeds for complete broadcast solutions
  • Redundant power supply (depending on configuration)

• Security:

  • AES-128 encryption for secure video streaming
  • Support for SSL/TLS encryption for secure web interface access

• Optional Accessories:

  • Rackmount kits for 1U server installations
  • Battery pack accessories for portable use

Use Cases:

• Live Event Streaming: Perfect for sports, concerts, or live broadcasts
• Contribution & Distribution: Ideal for news organizations, broadcasters, and production houses
• Remote Video Production: Due to its compact size and low-latency encoding, it’s used in mobile production environments, especially for on-site events.

The MGW Ace Encoder stands out in terms of high-efficiency video compression (HEVC) and portability, offering broadcasters and content producers a reliable solution for both high-quality and low-latency streaming.
