Panasonic AJ-HPX2100E +AJ-HVF21G +MIC

HD P2 B4 2/3″ Broadcast Camcorder with SDI out +viewfinder and Stereo Microphone

The Panasonic AJ-HPX2100E is a professional camcorder designed for broadcast, cinematography, and high-end production applications. It is part of the P2 HD family and features advanced video recording and broadcasting capabilities. B

1. Sensor and Imaging

• Type: 2/3-inch 3-CCD (Charge Coupled Device) imaging system.
• Sensor Resolution: 1920 x 1080 (Full HD).
• Color Filter: RGB (Red, Green, Blue) CCDs for improved color reproduction.

2. Recording Formats

• Recording Media: P2 cards (ExpressP2 cards supported).
• Recording Formats:
  • AVC-Intra 100/50 (High definition)
  • DVCPro HD (720p, 1080i)
  • DVCPRO50 (SD)
  • DVCPRO (SD)
  • MXF (Material Exchange Format) file-based recording.

3. Recording Resolutions

• 1080i (interlaced)
• 720p (progressive)
• 480i (standard definition)
• Frame Rate: Supports a wide range of frame rates, including 24p, 25p, 30p, 50p, and 60p (depending on format).

4. Optics

• Lens Mount: 2/3-inch bayonet mount for professional lenses.
• Lens Compatibility: Compatible with a wide range of high-quality professional lenses.

5. Viewfinder

• Type: 1.77-inch color LCD viewfinder.
• Resolution: 960 x 540 pixels.
• Functions: Offers features such as peaking, focus assist, and waveform monitor for precise operation.

6. Audio

• Audio Input: 2 XLR audio inputs with phantom power for professional microphones.
• Audio Format: 4-channel audio, supporting up to 48 kHz/16-bit audio.

7. Connectivity

• HD-SDI (Serial Digital Interface): 1 HD-SDI output for live video signal transmission.
• Component Output: For high-quality analog video signal output.
• IEEE 1394 (FireWire): Supports 1394 connectivity for data transfer.
• GENLOCK: Input for synchronization with other equipment in multi-camera setups.
• Timecode: In/out for synchronization with other devices.

8. Physical and Power

• Power Supply: DC input (12V) or V-mount battery.
• Power Consumption: Approximately 28 watts in operation.
• Dimensions: 225 mm (H) x 225 mm (W) x 470 mm (D) (without lens).
• Weight: Approximately 3.2 kg (without lens).

9. Additional Features

• High Sensitivity: 2,000 lux for clear imaging in low light conditions.
• Improved Signal-to-Noise Ratio (SNR): Better noise reduction for higher image quality.
• Timecode Display: For syncing with other equipment and multi-camera setups.
• Advanced Audio Features: Manual control for audio gain and limits, as well as professional-level input/output options.

10. Special Features

• Variable Frame Rate (VFR): Allows slow-motion or fast-motion effects in post-production.
• Focus Assist: Features such as peaking, zoom assist, and histogram to help with precise focus control.
• Waveform Monitor and Vectorscope: Onboard monitoring tools for evaluating signal quality.

11. Compatibility

• P2 Cards: Supports P2 cards, making it fully compatible with a professional file-based workflow. ExpressP2 cards are supported for faster data transfer speeds.

12. Recording Bit Rate

• AVC-Intra 100/50: Intra-frame codec with high-quality recording for broadcast and cinematography applications.

This camcorder is designed for high-quality video production, offering flexibility, durability, and various professional features ideal for broadcast and cinema applications.
