Vinten VISION 250 Flat Base Head

Vinten VISION 250 flat base fluid head

The Vinten VISION 250 is a fluid head designed for professional camera support, offering precision control and stability for medium-sized cameras. It’s part of Vinten’s VISION series, known for their high-performance fluid heads. Below are the key technical details for the Vinten VISION 250 flat base fluid head:

Key Specifications:

1. Weight:

   • The Vinten VISION 250 weighs approximately 3.6 kg (7.9 lbs) without the counterbalance system, making it lightweight for its class.

2. Load Capacity:

   • Supports camera loads ranging from 4 kg to 20 kg (8.8 lbs to 44 lbs), making it versatile for a wide range of camera sizes and configurations.

3. Counterbalance:

   • The Vinten VISION 250 features Vinten’s patented Perfect Balance system with 7 counterbalance steps. This system automatically adjusts to the weight of the camera, ensuring precise control and stability during operation.

   • The counterbalance range is suitable for cameras weighing between 4 kg (8.8 lbs) and 20 kg (44 lbs).

4. Pan and Tilt Movement:

   • Pan Tilt Drag: The fluid head uses a continuous pan and tilt drag adjustment to control the camera’s movement, ensuring smooth and precise motions.

   • Pan Range: 360° pan rotation for full flexibility in camera movement.

   • Tilt Range: +90° to -70° tilt range, allowing for versatile shooting angles.

5. Pan and Tilt Drag Settings:

   • The Vinten VISION 250 offers stepless drag control for both pan and tilt axes, allowing for the precise adjustment of movement resistance.

6. Base Type:

   • The flat base design allows it to be used on a variety of tripods or other support systems. The flat base typically includes a 3/8″ thread for mounting on different tripods.

7. Quick Release Mechanism:

   • The quick release plate system enables fast and easy camera mounting and removal.

8. Fluid Damping:

   • The fluid head is equipped with high-quality fluid damping for both pan and tilt axes to ensure smooth, controlled camera movements.

9. Temperature Range:

   • The Vinten VISION 250 is designed to function in extreme environments with a temperature range of -40°C to +60°C.

10. Height:

    • 170 mm (6.7 in) from the base to the top of the head.

11. Footprint:

    • The footprint of the Vinten VISION 250 is compact, ensuring ease of use and portability.

12. Build Material:

    • Constructed from high-strength aluminum alloy for durability and lightweight handling.

Additional Features:

• Dual Safety Mechanism: Ensures that the camera is securely locked and prevents accidental disengagement during use.

• Smooth, consistent movement for both panning and tilting, which is ideal for broadcast applications and high-end video production.

• Optional Accessories: Can be used with a variety of Vinten accessories, such as quick release plates, leveling bowls, and various tripod mounts.

This fluid head is ideal for professionals in the broadcast, film, and video production industries, offering a blend of precision, stability, and smooth performance.
