SONY PXW-FS5 MKI

PXW-FS5 MKI with charger and battery

The Sony PXW-FS5 is a compact and versatile Super 35mm camcorder designed for professional filmmakers and content creators.

1. Image Sensor

• Sensor Type: Super 35mm Exmor CMOS sensor
• Sensor Size: 23.6 x 13.3 mm (Super 35mm format)
• Resolution: 3840 x 2160 (4K) in UHD or 1920 x 1080 (Full HD)

2. Recording Formats

• Recording Codecs:

  • XAVC-L (High-efficiency, 4K and HD recording)
  • AVCHD (HD recording)
  • Proxy Recording (for lower resolution media)

• Frame Rates:

  • 4K UHD (3840 x 2160): 23.98p, 25p, 29.97p (XAVC-L)
  • Full HD (1920 x 1080): up to 120fps (slow-motion)
  • Slow Motion: Supports up to 240 fps (in Full HD)

3. Video Outputs

• HDMI: 1.4 output (for video and audio output to external devices)
• 3G-SDI: For output to monitors and recorders
• Timecode: BNC output for synchronized recording

4. Lens Mount

• Mount: Sony E-mount, compatible with E-mount lenses and PL-mount lenses (via adapter)

5. Viewfinder and Display

• Viewfinder: 0.39-inch OLED electronic viewfinder
• LCD Screen: 3.5-inch LCD display, 1920 x 1080 resolution

6. Audio

• Audio Inputs:
  • 2x XLR inputs (with phantom power support)
  • 3.5mm mini-jack microphone input
  • 3.5mm headphone jack
• Built-in Microphone: Mono mic for basic audio

7. Storage Media

• Dual SD/SDHC/SDXC Card Slots:
  • Supports UHS-I/II cards
  • Records in a range of formats (e.g., XAVC-L, AVCHD)

8. Autofocus

• Autofocus Type: Fast Hybrid AF (uses both phase-detection and contrast-detection)
• Focus Assist: Supports peaking and magnification functions for manual focus adjustments

9. Additional Features

• Slow & Quick Motion: 1 to 960 fps in HD
• S-Log3 & S-Gamut3: Provides extensive dynamic range and color grading flexibility.
• Zebra: 70%, 80%, 100% (adjustable)
• Built-in ND filters: 2, 4, and 6 stops (electronic control)

10. Power and Battery

• Battery: Sony BP-U30, BP-U60 (L-series)
• Power Consumption: Approximately 18W
• Operation Time: Around 3-4 hours with the BP-U60 battery (depends on usage)

11. Dimensions and Weight

• Body Size: 129 x 211 x 251 mm (without lens)
• Weight: Approx. 0.8 kg (1.76 lbs) (body only, without lens)

12. Connectivity

• Wi-Fi: Built-in for remote operation (via mobile app)
• USB: Supports USB 3.0 for data transfer
• LAN: Optional network connection for live streaming (requires accessory)

13. Other Features

• Picture Profiles: Various preset picture profiles for cinematic looks
• IR Remote Control: For remote camera control
• Customizable Buttons: To simplify and speed up access to functions during shooting

The Sony PXW-FS5 is a very flexible camera, ideal for various filming environments, especially for documentaries, independent films, and events. It supports high-quality 4K and HD video, slow-motion shooting, and high-end features like S-Log3 and built-in ND filters, making it suitable for both professionals and enthusiasts.
