Sony PMW-F55 4K +CA-4000 +BPU-4500A

Complete Studio camera set composed by:

Sony PMW-F55 4K (955 hrs use)

Sony DVF-L700 Studio LCD Viewfinder

Sony DVF-L350 LCD Viewfinder

AXS-R5 RAW Recorder

AXS-512S24 SXS Card

3x 256 Gb SxS Cards

Sony CBK-55F2K optical Lowpass Filter,

CBK-55PD ProRes/DNxHD codec board

Sony CA-4000 Fiber Adapter F55

Sony SKC-BP40 Power Booster Kit for CA-4000

Sony BPU-4500A Fiber 4K Baseband Processor

also available as extra possible :

C-MOTION Broadcast Camin iris and focus motors that can be remoted with the BPU

The Sony PMW-F55 is a digital cinema camera designed for high-end film production, offering advanced features suited for professionals.

Sensor

• Type: Super 35mm Exmor CMOS sensor
• Resolution: 4096 x 2160 (4K) and 1920 x 1080 (HD)
• Aspect Ratio: 17:9 (4K)

Image Processing

• Image Processor: Sony’s proprietary F55 Engine
• Recording Formats:
  • 4K (4096 x 2160)
  • 2K (2048 x 1080)
  • HD (1920 x 1080)
  • High Frame Rate (HFR) up to 240 fps in HD
• Recording Codecs:
  • XAVC (4K and HD)
  • ProRes (HQ, 422, 422 LT)
  • Uncompressed 16-bit RAW (via AXS-R5 recorder)
  • MPEG-2 (HD)

Lens Mount

• Mount Type: PL mount (can also use Sony FZ mount with an optional lens mount adapter)

Recording Media

• Primary Media: SxS Pro+ memory cards (XAVC, ProRes)
• Optional Media: AXS-R5 recorder for 16-bit RAW recording (uses AXS cards)

Frame Rates

• Standard:
  • 23.98, 24, 25, 30 fps for 4K and 2K
  • 50/60 fps for HD
• High Frame Rate:
  • Up to 240 fps in HD mode (with 2K/HD recording)

Dynamic Range

• Wide Dynamic Range: 14 stops, supports S-Log3 and S-Gamut3 (both color spaces and log curves designed for greater post-production flexibility)

Connectivity

• Outputs:
  • 4K (4096 x 2160) via 12G-SDI or 4x 3G-SDI
  • HD (1920 x 1080) via 3G-SDI
  • HDMI output (for monitoring)
• Audio Inputs:
  • 2 x XLR balanced inputs (4 channels of audio)
• Timecode: SMPTE timecode in and out

Power

• Power Supply: 14.4V DC (Sony V-Mount or AB Mount battery)
• Power Consumption: Approximately 30W

Viewfinder and Monitoring

• Viewfinder:
  • Optional 2.5-inch OLED viewfinder
  • External monitor support via SDI or HDMI
• LCD Screen: Optional LCD monitor

Size and Weight

• Body Dimensions: 167mm x 184mm x 343mm (6.57″ x 7.24″ x 13.50″)
• Weight: 3.8 kg (8.4 lbs) with the base configuration (body only)

Other Features

• Autofocus: Manual focus only (via lenses; autofocus capability depends on the lens used)
• Low-Light Performance: Excellent sensitivity due to Exmor CMOS sensor
• Color Science: Includes S-Log3 gamma for post-production flexibility, and wide color gamut (S-Gamut3)

The Sony PMW-F55 is designed for cinema-quality filming with a range of advanced recording and processing options, making it an ideal choice for film productions, commercials, and high-end video productions.
