Sony PMW-500 +CBK-VF01

PMW-500 (2660 hrs use from new) + CBK-VF01 viewfinder + Stereo Mic

The Sony PMW-500 is a professional camcorder designed primarily for broadcast and production environments. It is a shoulder-mount camera with advanced features suitable for high-quality video capture.

1. Image Sensor:

• Type: 3 x 2/3-inch Power HAD FX CCD sensors
• Resolution: 1920 x 1080 (Full HD)
• Effective Pixels: 1920 x 1080 for each sensor
• Aspect Ratio: 16:9 (HD)

2. Lens Mount:

• Type: B4 lens mount (interchangeable lens)
• Lens Support: 2/3-inch broadcast lenses
• Zoom Lens: Typically used with professional zoom lenses for ENG (electronic news gathering) applications.

3. Recording Format:

• Codec: XDCAM HD422 (MPEG-2 422)
• Bitrate: Up to 50 Mbps
• Recording Media: Dual SxS memory cards (ExpressCard-based, compatible with 64GB, 128GB, and 256GB cards)
• File Format: MXF (Material Exchange Format)

4. Video Resolution:

• 1080p: 1920×1080 (progressive scan)
• 1080i: 1920×1080 (interlaced scan)
• 720p: 1280×720 (progressive scan)

5. Frame Rates:

• 23.98p, 25p, 29.97p, 50i, 59.94i, 50p, 59.94p
• Overcranking: 50 fps in 720p for slow motion (up to 120 fps in specific modes)

6. Audio:

• Audio Channels: 4 channels (2 channels of XLR input, including microphone and line-level input)
• Sampling Frequency: 48 kHz
• Bit Depth: 16-bit/24-bit audio support
• Audio Input: XLR (balanced, professional)

7. Viewfinder and LCD:

• Viewfinder: 0.45-inch OLED viewfinder (HD)
• LCD Screen: 3.5-inch LCD panel with 16:9 aspect ratio, providing a clear image for monitoring during shoots.

8. Interfaces and Outputs:

• Video Outputs:
  • HD-SDI (BNC) for high-definition video output
  • Composite video output (RCA)
  • HDMI output
• Audio Outputs: XLR, AES/EBU, and analog audio outputs
• Timecode: In/Out, RS-422 for remote control
• Genlock Input: For synchronization with other equipment
• Remote Control: LANC remote control connector

9. Power and Battery:

• Power Consumption: Approximately 20W (when recording)
• Battery Type: Sony BP series (Lithium-ion batteries)
• Battery Runtime: Depends on the battery capacity, typically around 2 to 4 hours.

10. Dimensions and Weight:

• Dimensions: 234 mm (H) x 460 mm (W) x 233 mm (D) (without lens)
• Weight: Approx. 4.4 kg (9.7 lbs) (body only, excluding lens and accessories)

11. Other Features:

• Autofocus and Manual Focus: Fully manual lens control for focus, zoom, and iris adjustments.
• Slow & Quick Motion: Variable frame rate support for creating slow-motion or fast-motion video effects.
• Dual SxS Card Slots: For continuous recording, allowing one card to record while the other is being prepared for the next shot.
• Dual Link HD-SDI Output: To enable higher quality video transmission.
• HD-SDI and HDMI outputs for real-time broadcast or live feed transmission.

12. Software and Control:

• Camera Control: Via RM (remote control) or external control units.
• ND Filters: Built-in ND filters (1/4, 1/16, 1/64) to control exposure without adjusting the aperture.

13. Signal Processing:

• Signal-to-Noise Ratio: 59 dB or more
• Dynamic Range: Wide dynamic range with advanced processing for high-quality imagery.

This camcorder is well-suited for professional use, offering high-quality imaging, versatile recording options, and robust build quality.
