Panasonic AJ-HPX2100E +AJ-CVF100G

Description

HD P2 Camcorder 2/3″ with Viewfinder AJ-CVF100G

OPE: 00233×10 /P.on T.: 09684

The Panasonic AJ-HPX2100E is a professional camcorder designed for broadcast, cinematography, and high-end production applications. It is part of the P2 HD family and features advanced video recording and broadcasting capabilities.

1. Sensor and Imaging

Type: 2/3-inch 3-CCD (Charge Coupled Device) imaging system.
Sensor Resolution: 1920 x 1080 (Full HD).
Color Filter: RGB (Red, Green, Blue) CCDs for improved color reproduction.

2. Recording Formats

Recording Media: P2 cards (ExpressP2 cards supported).
Recording Formats:
- AVC-Intra 100/50 (High definition)
- DVCPro HD (720p, 1080i)
- DVCPRO50 (SD)
- DVCPRO (SD)
- MXF (Material Exchange Format) file-based recording.

3. Recording Resolutions

1080i (interlaced)
720p (progressive)
480i (standard definition)
Frame Rate: Supports a wide range of frame rates, including 24p, 25p, 30p, 50p, and 60p (depending on format).

4. Optics

Lens Mount: 2/3-inch bayonet mount for professional lenses.
Lens Compatibility: Compatible with a wide range of high-quality professional lenses.

5. Viewfinder

Type: 1.77-inch color LCD viewfinder.
Resolution: 960 x 540 pixels.
Functions: Offers features such as peaking, focus assist, and waveform monitor for precise operation.

6. Audio

Audio Input: 2 XLR audio inputs with phantom power for professional microphones.
Audio Format: 4-channel audio, supporting up to 48 kHz/16-bit audio.

7. Connectivity

HD-SDI (Serial Digital Interface): 1 HD-SDI output for live video signal transmission.
Component Output: For high-quality analog video signal output.
IEEE 1394 (FireWire): Supports 1394 connectivity for data transfer.
GENLOCK: Input for synchronization with other equipment in multi-camera setups.
Timecode: In/out for synchronization with other devices.

8. Physical and Power

Power Supply: DC input (12V) or V-mount battery.
Power Consumption: Approximately 28 watts in operation.
Dimensions: 225 mm (H) x 225 mm (W) x 470 mm (D) (without lens).
Weight: Approximately 3.2 kg (without lens).

9. Additional Features

High Sensitivity: 2,000 lux for clear imaging in low light conditions.
Improved Signal-to-Noise Ratio (SNR): Better noise reduction for higher image quality.
Timecode Display: For syncing with other equipment and multi-camera setups.
Advanced Audio Features: Manual control for audio gain and limits, as well as professional-level input/output options.

10. Special Features

Variable Frame Rate (VFR): Allows slow-motion or fast-motion effects in post-production.
Focus Assist: Features such as peaking, zoom assist, and histogram to help with precise focus control.
Waveform Monitor and Vectorscope: Onboard monitoring tools for evaluating signal quality.

11. Compatibility

P2 Cards: Supports P2 cards, making it fully compatible with a professional file-based workflow. ExpressP2 cards are supported for faster data transfer speeds.

12. Recording Bit Rate

AVC-Intra 100/50: Intra-frame codec with high-quality recording for broadcast and cinematography applications.

This camcorder is designed for high-quality video production, offering flexibility, durability, and various professional features ideal for broadcast and cinema applications.
