Grass Valley GVG LDX 82

Grass Valley LDX-82 Fiber

The Grass Valley LDX 82 Series is a high-performance camera platform designed for live HD production, offering flexibility and advanced imaging capabilities.

Key Features:

• Imaging Technology: Equipped with three 2/3-inch Xensium-FT CMOS sensors, the LDX 82 Series delivers high sensitivity and dynamic range, ensuring superior image quality in various lighting conditions.

• Resolution and Formats: The camera supports HD 1080i and 720p formats, with certain models capable of switching between 1080i, 720p, and 1080PsF. The LDX 82 Elite model, for instance, offers this flexibility, allowing adaptation to different production requirements.

• Transmission Options: The LDX 82 Series features a dockable transmission system, enabling the selection of 3G Fiber, 3G Triax, or XF transmission adapters. This design provides flexibility and cost-effective solutions for various applications.

• Advanced Features: Models like the LDX 82 Elite include features such as Power Curves for shooting under challenging conditions and Color Protect to correct lighting issues. These enhancements support extended color gamut, including ITU-R BT.2020.

• Physical Specifications: The camera head has a compact design with dimensions of 170 mm (width), 200 mm (depth), and 180 mm (height), and weighs approximately 2.1 kg (4.6 lbs.) including the handgrip and shoulder pad. It operates within a temperature range of -20°C to +45°C.

For comprehensive technical details and operational guidance, refer to the LDX 82 Series User’s Guide.
