CANON CN7x17 KAS S/P1 PL 17-120mm +SS-41IASD

PL Mount Zoom lens 17-120mm with servo zoom and focus remotes (with E-mount adapter)

The Canon CN7x17 KAS S/P1 PL 17-120mm is a professional cinema zoom lens designed for high-end video production. Here are the key technical details:

General Specifications:

• Focal Length: 17-120mm
• Zoom Ratio: 7x
• Lens Mount: PL Mount (Positive Lock)
• Maximum Aperture: f/2.95
• Minimum Aperture: f/22
• Iris Blades: 11 (providing a smooth, rounded bokeh)
• Image Format: Covers Super 35mm format
• Weight: Approx. 2.7 kg (5.95 lbs)
• Length: 186 mm (7.32 in)
• Diameter: 114 mm (4.49 in)
• Front Element Diameter: 114 mm (standard for matte box compatibility)
• Power Zoom/Manual Zoom: Manual zoom

Optical Features:

• Optical Design: 18 elements in 12 groups
• Focus Rotation: 200° (full rotation for precise manual focus adjustments)
• Zoom Rotation: 120°
• Focus & Zoom Mechanism: Parfocal (maintains focus throughout the zoom range)
• Minimum Focusing Distance: 0.85 m (33.5 in) at 17mm, 1.2 m (47.2 in) at 120mm
• Lens Coating: Canon’s advanced coating technology for reduced flaring, ghosting, and enhanced color reproduction

Key Features:

• Electronic Communication: The lens communicates with the camera’s electronic systems for features such as servo zoom, iris control, and metadata transfer.
• Servomotor (S/P1 version): The servo motor allows for smooth, controlled zooms with a precise interface.
• Dual I/O for Focus & Zoom (for electronic control)
• Compatibility: Works with a wide range of Super 35mm cameras, including ARRI, Canon, Sony, and others with PL mount compatibility.

Other Notable Aspects:

• Built-in Image Stabilization: Yes, for steady shots.
• Weather Sealing: The lens is designed with a robust build to withstand the challenges of outdoor filming.
• Lens Design: Cine-style design optimized for precise manual control in the demanding environments of cinema production.

This lens is particularly suitable for high-end film and television productions, providing sharp image quality, a wide focal range, and reliability in a variety of shooting environments.
